AD-1611 Optical Communication Adapter
Enables safe data output from an explosion-protected balance/scale installed in an EX-hazardous area
Highlights
Features
Downloads
- Receives optical data from a balance/scale with an optical connector (e.g. EK-AEP series) and transmits electric signals to an external device such as a printer or PC through RS-232C or USB*1
- Three optical fiber cable lengths (10 m, 30 m, and 60 m) available to match the distance between the balance/scale and the AD-1611
- Requires no AC adapter for power supply when connected to a PC via USB*2
*1 The communication is unidirectional and the AD-1611 cannot transmit commands from the external device/PC to the balance/scale. The AD-1611 itself isn’t explosion-protected.
*2 Only a PC can be connected to the USB port of the AD-1611. A USB cable (type B male – type A male, 1 m) is provided as standard.
Highlights
- Receives optical data from a balance/scale with an optical connector (e.g. EK-AEP series) and transmits electric signals to an external device such as a printer or PC through RS-232C or USB*1
- Three optical fiber cable lengths (10 m, 30 m, and 60 m) available to match the distance between the balance/scale and the AD-1611
- Requires no AC adapter for power supply when connected to a PC via USB*2
*1 The communication is unidirectional and the AD-1611 cannot transmit commands from the external device/PC to the balance/scale. The AD-1611 itself isn’t explosion-protected.
*2 Only a PC can be connected to the USB port of the AD-1611. A USB cable (type B male – type A male, 1 m) is provided as standard.
Features
| Power supply | AC adapter or USB |
| Operating temperature | −10 to 40 ˚C/32 to 104 ˚F, 85% RH or less (no condensation) |
| Baud rate | According to the value set on the balance |
| Receiving connector | F05 (IEC 60874-17, F05 type) |
| Sending connector | RS-232C (D-Sub 9 pin) or USB (type B) |
| Optical transmission distance | Max. 60 m (no extension available) |
| Dimensions | 160 (W) × 58 (D) × 38 (H) mm |
| Net weight (main unit only) | Approx. 380 g |
| Standard accessories | AC adapter, USB cable |
