- Enables a PC (with communication software such as WinCT installed) to wirelessly receive data from and send commands to a Bluetooth® compatible scale such as the SJ-WP-BT series through its USB port*1
- Requires no cable connection, which can compromise the sealing of a waterproof scale
*1 The driver software for the AD-8541-PC is automatically installed with Windows 8.1 or later. If the driver cannot be installed, download it from here. WinCT is also downloadable for free.
Highlights
- Enables a PC (with communication software such as WinCT installed) to wirelessly receive data from and send commands to a Bluetooth® compatible scale such as the SJ-WP-BT series through its USB port*1
- Requires no cable connection, which can compromise the sealing of a waterproof scale
*1 The driver software for the AD-8541-PC is automatically installed with Windows 8.1 or later. If the driver cannot be installed, download it from here. WinCT is also downloadable for free.
Features
| Supported operating system | Windows XP/Vista/7/8.1/10, 32/64 bit |
| Operating environment | –10 to 40 ˚C / 14 to 104 ˚F, 85% R.H. or less (no condensation) |
| Power supply | From USB port |
| Communication range | Max. 10 m (line of sight) |
| Wireless communication module | EYSHCNZXZ (TAIYO YUDEN CO., LTD.) Bluetooth® 4.2 (Bluetooth® Low Energy) |
| Serial communication parameters | Baud rate: 2400 bps Bit length / parity: 7 bit / even Stop bit: 1 bit |
| External dimensions | Approx. 24 (W) × 12 (H) × 74 (D) mm |
| Net weight | Approx. 15 g |
