MC Series Mass Comparators
For management of masses in the OIML Class F1 or below
Highlights
Features
Downloads
- Stabilizing filter to minimize errors due to drafts or vibrations
- Extra decimal place that also makes it possible to monitor fine weight changes with heavy tare weights
- Auto-centering pan to avoid corner-load errors and ensure higher accuracy (option for MC-1000/6100/10K/30K)
- Internal calibration mass for simplified calibration of the balance
- Equipped with a glass breeze break (MC-1000/6100) or simple breeze break (MC-10K/30K) as standard
- Fast stabilization of approx. 1.5 seconds
- Large bright vacuum fluorescent display
- GLP/GMP/GCP/ISO compliant output
- Multiple weighing units: g, kg*, oz, ozt, ct, mom, dwt, grain, specific gravity, and a user-programmable unit for conversion applications (either tael or tola can be added upon request)
- Data memory function
- Counting mode with the Automatic Counting Accuracy Improvement (ACAI) function
- Percent mode function
- Animal weighing (hold) function
- Accumulation (M+) function (MC-10K/30K/100KS)
- Comparator function with buzzer
- Auto power on/off function
- Underhook function
- Density determination function
- Windows Communication Tools software (WinCT) on CD-ROM
- Quick reference card provided
* kg for MC-100KS only
Highlights
- Stabilizing filter to minimize errors due to drafts or vibrations
- Extra decimal place that also makes it possible to monitor fine weight changes with heavy tare weights
- Auto-centering pan to avoid corner-load errors and ensure higher accuracy (option for MC-1000/6100/10K/30K)
- Internal calibration mass for simplified calibration of the balance
- Equipped with a glass breeze break (MC-1000/6100) or simple breeze break (MC-10K/30K) as standard
- Fast stabilization of approx. 1.5 seconds
- Large bright vacuum fluorescent display
- GLP/GMP/GCP/ISO compliant output
- Multiple weighing units: g, kg*, oz, ozt, ct, mom, dwt, grain, specific gravity, and a user-programmable unit for conversion applications (either tael or tola can be added upon request)
- Data memory function
- Counting mode with the Automatic Counting Accuracy Improvement (ACAI) function
- Percent mode function
- Animal weighing (hold) function
- Accumulation (M+) function (MC-10K/30K/100KS)
- Comparator function with buzzer
- Auto power on/off function
- Underhook function
- Density determination function
- Windows Communication Tools software (WinCT) on CD-ROM
- Quick reference card provided
* kg for MC-100KS only
Features
| Model | MC-1000 | MC-6100 | MC-10K | MC-30K | MC-100KS |
| Capacity | 1100 g | 6100 g | 10.1 kg | 31 kg | 101 kg |
| Readability | 0.0001 g | 0.001 g | 0.01 g | 0.1 g | |
| Repeatability (Standard deviation)** | 0.0005 g (for 1 kg) 0.0004 g (for 500 g) 0.001 g**** |
0.004 g (for 5 kg) 0.0015 g (for 2 kg) 0.01 g**** |
0.005 g (for 10 kg) 0.004 g (for 5 kg) 0.01 g**** |
0.015 g (for 20 kg) 0.1 g**** |
0.2 g (for 100 kg) 0.1 g (for 60 kg) |
| Linearity | ±0.003 g | ±0.03 g | ±0.03 g | ±0.2 g | ±2 g |
| Sensitivity drift (10 °C to 30 °C)*** | ±2 ppm/°C | ±3 ppm/°C | ±6 ppm/°C | ||
| Weighing pan | 128 mm × 128 mm | 165 mm × 165 mm | 270 mm × 210 mm | 386 mm × 346 mm | |
** Repeatability when the auto-centering pan or an automatic loading machine is used under good ambient conditions or loading / unloading weight at the same position with an automatic loading machine.
*** When automatic self-calibration is not used.
**** When an auto-centering pan or an automatic loading machine is not used.
