TM-2917 Non-Invasive Blood Pressure Module
A&D has newly released the TM-2917 Blood Pressure Module, which is compatible with the previous TM-2915 model. The TM-2917 can select either inflation or deflation measurement mode.
Highlights
Features
Downloads
- Inflation or deflation measurement mode
- Advanced measurement algorithm
- Adoption of a wide range cuff (22-42 cm) as well as 5 other types of cuffs
- Dual-rolling pump
- Equipped with LCD display
- 5-12 V power source
- IHB screening function
- ISO:81060-2 clinical protocol validated
- Includes the well-established ECEV*
*ECEV – Electric Control Exhaust Valve
Highlights
- Inflation or deflation measurement mode
- Advanced measurement algorithm
- Adoption of a wide range cuff (22-42 cm) as well as 5 other types of cuffs
- Dual-rolling pump
- Equipped with LCD display
- 5-12 V power source
- IHB screening function
- ISO:81060-2 clinical protocol validated
- Includes the well-established ECEV*
*ECEV – Electric Control Exhaust Valve
Features
| Item | TM-2917 | |
| Blood pressure measurement | Oscillometric method | |
| Operating Modes | Set either Inflation or Deflation mode | |
| Patient Applications | Adult, Children, Neonatal | |
| Pressure detection | For measurement: For safety circuit: |
Semiconductor pressure sensor Semiconductor pressure sensor |
| Measurement range | Pressure: Pulse Rate: |
0 to 299 mmHg 30 to 240 bpm |
| Measurement Accuracy | Pressure: Pulse Rate: |
±3 mmHg over full range in operating conditions ±2% or ±2 BPM, whichever is greater |
| Systolic Range | (Inflation) Adult: Neonatal: (Deflation) Adult: Neonatal: |
60 to 280 mmHg N/A 40 to 280 mmHg 40 to 130 mmHg |
| DIA Range | (Inflation) Adult: Neonatal: (Deflation) Adult: Neonatal: |
40 to 200 mmHg N/A 20 to 200 mmHg 20 to 100 mmHg |
| Scale interval | Pressure: Pulse Rate: |
1 mmHg 1 bpm |
| Inflation method | Pump | Rolling pump 10 s or less/ 0→300 mmHg |
| Exhaust system | Constant exhaust: Rapid exhaust: |
Automatic deflation controlled by solenoid valve Rapid exhaust by opening of solenoid valve for controlled exhaust and rapid exhaust |
| Electrical rating | Rated power supply voltage: Power input: |
Direct current +5 to +12 V Not more than 8 VA |
| Serial communication | Standardl: Logic levels: Data-flow control: |
Based on RS232C TTL (3.3V) signal voltage level RTS from NIBP MODULE only (Non-use CTS) |
| Operating Conditions | Temperature: Humidity: Air pressure: |
0˚C to 60˚C Not more than 85%RH (no condensation) 700 – 1060hPa |
| Storage environment | Temperature: Humidity: Pressure: |
-20 to +70°C 95%RH or less (with no condensation) 700 – 1060hPa |
| External dimensions | 60(H) x 39(W) x 104.5(D) | |
| Weight | 260g | |
| NIBP Accuracy | Meets ISO 81060-2:2013 | |
| Safety & Regulatory Standards | IEC 60601-1:2005+AMD1:2012, IEC 60601-1-2:2014, IEC 810601-2-30:2018 ISO 81060-2:2013, IEC 62304:2006 | |
| Service life | Time Cycles |
6 years 100,000 |
