LC-4102 (Aluminum) For small and medium capacity weighing system,single point compact load cells

• Parallelogram-type construction
• Temperature compensation maintains both zero and span from -10 °C to +40 °C (+14 °F to +104 °F)
• Deadweight up to 80 % of capacity. Load weight and deadweight up to 180% of capacity
• Moisture proof
• Compact and lightweight

Rated capacities ……………………..10 kgf, 15 kgf, 30 kgf, 60 kgf, 150 kgf
Rated output ……………………………1 mV/V+15/-0%
Maximum deadweight …………….80% of rated capacity
Maximum safe overload ………….300% of rated capacity
Combined error ………………………±0.015% of rated output
Creep ………………………………………±0.05% of rated output/hour
Zero balance …………………………..20±5% of rated output
Compensated
temperature range …………………-10 °C to +40 °C/+14 °F to +104 °F
Recommended
excitation voltage ……………………12 V
Maximum
excitation voltage …………………..15 V
Input terminal resistance ………Approximately 400 Ω
Output terminal resistance……350 Ω ± 5 Ω
Insulation resistance ……………Greater than 5000 MΩ at DC50 V
Temperature effect
Zero ………………………………………0.004% of rated output/°C
Span …………………………………….0.0014% of rated output/°C Typ.
Platform size ………………………..400 × 400 mm/15.8 ×15.8 inches
Cable length ………………………..1.5 m/59 inches
