- Calibrated for 4 corner loads
- IP65, IP67
- Extremely durable structure built to withstand excessive loads and impacts
Highlights
- Calibrated for 4 corner loads
- IP65, IP67
- Extremely durable structure built to withstand excessive loads and impacts
Features
| Rated output | 1.5mV/V±5% | |
| Safe load limit | 500% of R.C. | |
| Ultimate safe overload | 1000% of R.C. | |
| Combined error | 0.02% of R.O. | |
| Recommended excitation voltage | DC5 to 12V | |
| Maximum excitation voltage | DC15V | |
| Zero balance | ±5% of R.O. | |
| Input terminal resistance | 1.13kΩ ±100Ω | |
| Output terminal resistance | 1kΩ ±10Ω | |
| Insulation resistance | 2000MΩ/DC50V | |
| Compensated temperature range | –10°C to 40°C | |
| Temperature effect | Zero | 0.014% of R.O./10°C Typ. |
| Span | 0.011% of Load/10°C Typ. | |
| Cable diameter/Length | φ4/1.5m | |
| Maximum platform size | 400 mm × 400 mm | |
| Dustproof/waterproof | IP65 * | |
* Although this load cell is rated IP65 it can be submerged up to 1m in water for up to 30 minutes similar to the IP67 rating.
